High Efficiency R290 EVI DC Inverter air source heat pump for Heating Cooling Hot Water

Short Description:


  • Model: NL-FLM50-190/R290
  • MOQ: 5
  • Place of Origin: Guangdong,China
  • Rated heating capicity: 19kw
  • Rated cooling capicity: 16.5kw
  • Max input power: 5.4kw
  • Delivery Time: around 25 days
  • Payment Terms: Bank Transfer,PayPal
  • Certification: CE,ERP
  • Voltage: 380-415V-Inverter~3 phase
  • Max water outlet temperature: 80c
  • Product Detail

    Product Tags

    1. How Does an Air Source Heat Pump Work?

    Air source heat pumps absorb heat from outdoor air and transfer it indoors for space heating, cooling, and hot water production. Even at low ambient temperatures, modern inverter heat pumps can operate efficiently.

    High efficiency: Up to 4–5 times more efficient than electric heating

    All-in-one solution: Heating, cooling, and domestic hot water

    Renewable energy: Utilizes free energy from the air

    Low carbon emissions: Supports sustainable building goals

    product-NULITE-img



    2. R290 vs R32 Heat Pumps

    R290 and R32 are two common refrigerants used in modern heat pumps. R290 offers lower environmental impact and higher outlet water temperatures, making it increasingly popular in Europe.

    Key Feature R290 R32
    GWP 3 675
    Max Water Temperature Up to 75°C Up to 60°C
    Environmental Compliance Excellent Good
    Long-Term Market Outlook Preferred Choice Transitional Solution

    Why Choose R290?

    Ultra-low environmental impact

    Higher water temperature output

    Better aligned with future regulations

    Ideal for sustainable heating projects

    product-NULITE-img

    3. Heat Pump vs Gas Boiler

    Heat pumps provide a more energy-efficient and environmentally friendly alternative to traditional gas boilers. They can significantly reduce energy consumption and operating costs.

    Higher efficiency: COP up to 5.0

    Lower operating costs: Reduced energy bills

    Reduced emissions: No on-site combustion

    Multi-functional: Heating, cooling, and hot water in one system

    Comparison Item Heat Pump Gas Boiler
    Energy Efficiency COP 3–5 85–95%
    Energy Source Electricity + Renewable Air Energy Natural Gas
    Operating Cost Lower Higher
    Carbon Emissions Low High
    Heating Function
    Cooling Function
    Domestic Hot Water
    Environmental Impact Excellent Moderate
    Long-Term Savings High Limited



    4. Are Heat Pumps Effective in Cold Climates?

    Modern EVI heat pumps are specifically designed to deliver reliable heating performance in harsh winter conditions and low ambient temperatures.

    Low-temperature operation: Down to -25°C or below

    Stable heating output: Reliable winter performance

    EVI technology: Enhanced efficiency in cold regions

    Ideal for northern climates: Suitable for Europe and North America

    product-High Efficency R290 EVI DC Iinverter air source heat pump for Heating Cooling Hot Water-NULI

    5. Best heat pump for Underfloor Heating Systems

    Underfloor heating systems operate at lower water temperatures, making them an ideal match for high-efficiency air source heat pumps.

    Low-temperature heating: Perfect system compatibility

    Higher energy savings: Improved seasonal efficiency

    Uniform comfort: Even heat distribution

    Quiet operation: Enhanced indoor comfort

    6. How to Choose the Right Heat Pump Size

    Selecting the correct heat pump capacity is essential for achieving maximum efficiency and long-term performance.

    Building size: Heating area affects capacity selection

    Climate conditions: Colder regions require larger capacities

    Insulation level: Better insulation reduces heating demand

    Professional sizing: Ensures optimal performance and efficiency

    dc inverter heat pump Unit NL-FLM30-100II/R290 NL-FLM30-130II/R290 NL-FLM50-160II/R290 NL-FLM50-190II/R290 NL-FLM80-250II/R290
    Heating capacity (A7C/W35C) W 10000 12800 16000 19000 25200
    Input power (A7C/W35C) W 2410 2970 3750 4530 5385
    DHW capacity (A7C/W55C) W 9500 11300 15500 16800 23300
    Input power (A7C/W55C) W 3150 3600 5000 5500 7580
    Cooling capacity (A35C/W18C) W 10000 11000 14000 16500 25900
    Input power (A35C/W18C) W 2950 3600 4260 5400 7800
    Voltage V/Hz 220V-240V-Inverter-1N 380V-415V-Inverter-3N 380V-415V-Inverter-3N 380V-415V-Inverter-3N 380V-415V-Inverter-3N
    Rated water temperature DHW:55℃ / Heating:45℃ / Cooling:12℃ DHW:55℃ / Heating:45℃ / Cooling:12℃ DHW:55℃ / Heating:45℃ / Cooling:12℃ DHW:55℃ / Heating:45℃ / Cooling:12℃ DHW:55℃ / Heating:45℃ / Cooling:12℃
    Max water temperature 75℃~80℃ 75℃~80℃ 75℃~80℃ 75℃~80℃ 75℃~80℃
    Rated water flow m³/h 1.7 2.1 2.7 3.1 4.3
    Refrigeration / R290 R290 R290 R290 R290
    Rated of waterproof / IPX4 IPX4 IPX4 IPX4 IPX4
    Control mode / Heating / Cooling / DHW / Heating+DHW / Cooling+DHW Heating / Cooling / DHW / Heating+DHW / Cooling+DHW Heating / Cooling / DHW / Heating+DHW / Cooling+DHW Heating / Cooling / DHW / Heating+DHW / Cooling+DHW Heating / Cooling / DHW / Heating+DHW / Cooling+DHW
    Compressor - Form / Double-rotor type Double-rotor type Double-rotor type Double-rotor type Double-rotor type
    Compressor - Quantity / 1 1 1 1 1
    Compressor - Brand / Panasonic Full Inverter +EVI Compressor Panasonic Full Inverter +EVI Compressor Panasonic Full Inverter +EVI Compressor Panasonic Full Inverter +EVI Compressor Panasonic Full Inverter +EVI Compressor
    Net weight Kg 105 112 145 150 175
    Noise level dB(A) ≤51 ≤51 ≤53 ≤53 ≤58
    Fan - Form / Full DC fan motor (low noise) Full DC fan motor (low noise) Full DC fan motor (low noise) Full DC fan motor (low noise) Full DC fan motor (low noise)
    Fan motor PCS 1 1 2 2 3
    Water heat exchanger / Sweden SWEP Plate heat exchanger (Main road)+Denmark Danfoss Plate heat exchanger(EVI road) Sweden SWEP Plate heat exchanger (Main road)+Denmark Danfoss Plate heat exchanger(EVI road) Sweden SWEP Plate heat exchanger (Main road)+Denmark Danfoss Plate heat exchanger(EVI road) Sweden SWEP Plate heat exchanger (Main road)+Denmark Danfoss Plate heat exchanger(EVI road) SANHUA+Danfoss Plate heat exchanger
    Auxiliary Element built-in French / 3KW 3KW 3KW 3KW 3KW
    Circulation pump built-in SHIMGE / Inverter Water Pump (water head 12 meters) Inverter Water Pump (water head 12 meters) Inverter Water Pump (water head 12 meters) Inverter Water Pump (water head 12 meters) Inverter Water Pump (water head 12 meters)
    Expansion tank built-in L 5 5 5 5 5
    Ambient temperature (-25℃ -- 43℃) (-25℃ -- 43℃) (-25℃ -- 43℃) (-25℃ -- 43℃) (-25℃ -- 43℃)
    Inlet pipe diameter mm DN25 DN25 DN25 DN25 DN40
    Outlet pipe diameter mm DN25 DN25 DN25 DN25 DN40
    Net size mm 1080×499×970 1080×499×970 1080×499×1365 1080×499×1365 1080×499×1653
    Packing size mm 1120×510×1100 1120×510×1100 1120×510×1490 1120×510×1490 1120×510×1785
    20'GP container loading pcs 44 44 22 22 22
    40'HQ container loading pcs 92 92 46 46 46
    E.P Energy Level(EU certified) pcs 35℃ A+++ 35℃ A+++ 35℃ A+++ 35℃ A+++ 35℃ A+++

    7. Heat Pump Solutions for Hotels

    Heat pumps provide hotels with an energy-efficient solution for space heating, cooling, and large-scale hot water production.

    Continuous hot water supply: Meets high occupancy demand

    Lower operating costs: Significant energy savings

    Scalable capacity: Suitable for small and large hotels

    Sustainable operation: Supports green building initiatives

    product-NULITE-img

    8.Why Choose NULITE?

    Founded in 2003 – Over 23 years of heat pump expertise

    China–Singapore Joint Venture – Global vision, local excellence

    800+ Employees – 2 manufacturing bases and 1 marketing center

    200,000+ m² Production Area – 12 automated production lines

    10 Certified Laboratories – Advanced R&D and product testing

    1,000,000+ Units Annual Capacity – Reliable large-scale production

    National High-Tech Enterprise – Innovation-driven development

    product-NULITE-img

    9. Get Your Customized Solution

    Location + Application + Required Water Temperature – Share your project requirements with us

    (Example: Hamburg + Hotel + 85°C)

    Full Specification Sheet – Detailed technical information for product evaluation

    Certificate Package – CE, CB, RoHS, ErP, ISO and other available certifications

    Customized Quotation – Tailored product and pricing proposal for your project

    Free Technical Consultation – Professional support from our experienced engineering team



    NULITE – Your Trusted Partner for Sustainable Heating Solutions
